IGNIS HEAD LIGHTS – ZETA TO ALFA UPGRADATION.

Continues …


This DIY write up continuous with a good intention to anyone who is interested to upgrade their headlights in their car irrespective of the type of car that they own.
I am sure, it would be useful for such a car enthusiast as I did in-depth study, also discussed with our senior forum members, explained the doubts and intricacies on both plus and minus sides.
One thing I felt, it would be always better to get the version of the car that satisfies you instead of aftermarket fitments and taking risk.

I know, for a car enthusiast this is sometimes inevitable as what happened to me.[lol]
But, I am happy that I have learned many things and could share for others in this forum,which one cannot find anywhere else.

My only request, please read line by line all my write ups over this topic so that it would make you to completely understand. Right?




I AM SUMMARIZING EVERYTHING FOR EASY UNDERSTANDING:

1. The original wiring harness in Alfa Model has independent connection in the Right and Left sides. Note the special multiple wires Plug Socket that is not a regular three pin type. See Image Here.
IGNIS 1.jpg




2. The LED Bulbs inside the housing particularly inside the Projector lens are not of a removal design like the aftermarket. They are multiple diodes embedded on a mother board and the Projector lens is specially designed to focus the beam.
See the Baleno Alfa image and video link here.

IGNIS 2.jpg





3. The DRLs are also of high quality design with its own Driver / Heat sinks inbuilt and inside.
See the Baleno Alfa image and video link here.

IGNIS 3.jpg





IN MY CASE:


4. The Seller utilized the original IGNIS Alfa lights (Factory Seconds - GOD ONLY KNOWS that how he gets them for every car!)) reconfigured the wiring EXTERNALLY by adding a DUAL HEAD LIGHTS DIP/DIM CONTROLLER in the battery side of LEFT HEAD LIGHT by connecting the OE 3 PIN PLUG there and left unused the RIGHT SIDE OE 3 PIN PLUG.

(DUAL HEAD LIGHTS DIP/DIM CONTROLLER is to be connected with original LEFT head light three pin plug (Hi Beam, Low Beam and Common) that will control the shutter inside both of side projectors for Hi/Low Beams, by the original switch attached with the steering wheel. This type of wiring harness ensures plug and play, no OE wire cutting[:D].)

Note: No LED Driver / Heat sink is kept OUTSIDE in the new model Alfa Led Head lights. The externally attached Ballast can only be seen in some HID models of Head lights in some versions of Baleno as in the picture that I posted earlier.

In my next write up, I will show what all I purchased from Amazon.in and how neatly I have done by taking into all safety precautions.

See you later.[drive]

Regards,
Dr MUDHAN

Last edited:
Thread Starter #63

Dr MUDHAN

Honoured Member
Joined
Sep 3, 2013
Messages
764
Likes
1,548
Location
COIMBATORE
IGNIS HEAD LIGHTS – ZETA TO ALFA UPGRADATION.
Continues …



COMPLETE – DIY- PROCESS:

As I have already Shared /Described some of the steps carried out, and without repeating the same, would like to summarize FINALLY here:

1. Removed the Battery terminal, first Negative and then Positive.
2. Removed the front bumper along with grill fully after carefully removing the Fastener Clips / 10mm bolts from Top, Down and Fender sides, also after detaching Fog Light couplers. (Safely kept all the Fasters and Bolts)
3. Removed the Headlights from both sides after removing those three 10mm bolts and by detaching parking light / indicator light couplers.
4. Made ready the wiring harness in the aftermarket ALFA headlights Right and Left sides RESPECTIVELY by checking all the inputs with my old Laptop 12V adopter, insulating neatly with Polyolefin tubes.
5. Installed the new lights in their respective position and connected the center points as it is a dual head light controller setup. And the joints were neatly insulated, covered with black poly sheet for neat looking and more water proofing, tucked inside the frame.
6. The Parking and DRLs 'Dim while HL- ON' connections connected to OE Parking coupler by simply inserting and insulating it without wire cutting at both sides. Covered them and the right side unconnected 3 PIN with black poly sheet to protect from water & hide them.
7. Connected the Main Battery terminals, along with positive and negative wires of the DIM/DIP Controller at the LEFT side HL, also negative of the DRLs. to Battery.
8. Connected the 3 PIN coupler to Left side HL, provided via controller.
9. Checked the HL DIM/DIM and parking – Okay.
10. Opened the engine side FUSE BOX, identified the ACC as at the Blue wire, neatly inserted the DRLs Positive, carefully covered and closed the lid. (Please note, this has to be done while engine is OFF and also the Ignition ACC position as well to ensure the DRLs should be ON only when the IGNITION is in ACC mode or while Engine is running. Found, everything okay.[:D]

PLEASE FOLLOW THE PICTURES / DIAGRAM / VIDEOS HERE FOR PROPER UNDERSTANDING.
